HEAT EXCHANGERS and AXIAL FLOW FANS
Finned heat exchangers - numerous
Heat exchangers, evaporators, radiators. Mild steel galvanised exterior, previously used as ammonia evaporators for freezers.
Details (photos to come)
Made by Ellis Hardie Symington in 1968. Refrigerant Ammonia. Size 1944. Supplied April 1968. Size 2040 x 1700mm. 57 double pass finned pipes 525mm width. Very good condition.
Fans – x6
Top level chiller no 3.
6 fans. 1095 x 1095 x 500 deep plus length of cones. Aluminium fans and cones. Galvanised mild steel casings.
Motor details. 2.2kW, 50 Hz, 960 rpm, 3 phase induction motors, 1997, 41kg.
Fans – x60
Block 3 level 4. Freezer rooms 22, 23, 24, 25, 26, 27. 10 off each room.
60 fans. Frames galvanised steel. Cowlings and cones aluminium. Fan blades (8) aluminium. Fan blade hub (aluminium) marked AXIA Type D 40 Dia T Size 1216 x 1216 depth 570 plus hubs.
Motor details. Motor no K5F6 Compton Parkinson 950 rpm 8A 5 hp Frame D215 Class E insulation 3 ph 50 Hz 380/440V
Air Inlet side
Air outlet side
Motor with cowling removed
Fans – x14
Block 8a Level 3
14 fans too high to get details. As seen painted steel casings aluminium fans, cowling and cones.
Fans – x6
Top level block west of wooden block
6 fans with plastic impellers. 710mm OD 608mm ID Plastic casing, 8 blades
Motor details from plate. BS5000 Part 99 AC Motor, Hawker Siddeley CROMPTON PARKINSON LTD. Frame D100LA Serial no X984972 Output kW 2.2 Rev/min 1420 IP54 V400 A 5.1 Hz 50 Phase 3 Rating MC (80 deg rise) Insulation class Bearings DE6206Z NDE6205.
Fans – x32
Lamb processing room, Boning room
32 Fans Galvanised steel frames, aluminium blades
Fans – x14
Front of office
14 axial flow fans most still connected to ducting. – photos to come.
PURCHASING
Please contact us if interested in purchasing any items.
If required we will dismantle and photograph all components to give a better understanding of what is being offered.
The units are free running and generally in very good mechanical condition with some requiring minor cosmetic attention.
